G800 Linear‑Motor High‑Speed Machine
Technical Parameters
| Item | Unit | G800 |
|---|---|---|
| X/Y/Z axis travel | mm | 800/700/500 |
| Spindle nose to work surface distance | mm | 200‑700 |
| Workbench dimension | mm | 800*800 |
| Max workbench bearing capacity | kg | 300 |
| T‑slot specification | mm | 7‑22*135 |
| Spindle type | — | Built‑in |
| Spindle taper | — | HSK‑A63 |
| Spindle speed | rpm | 20000/24000 |
| Spindle motor power | kw | 15/18 |
| Tool magazine capacity | T | 24 |
| X/Y/Z axis rapid feed | m/min | 60/60/60 |
| X/Y/Z axis cutting feed | m/min | 1‑20 |
| X/Y/Z linear motor thrust | N | 14250/14250/7650 |
| Positioning accuracy | mm | 0.003 |
| Repeated positioning accuracy | mm | 0.002 |
| X/Y/Z linear guide specification | mm | 35/35/35 |
| Air pressure requirement | kg/cm² | 6 |
| Main machine overall dimension | mm | 5100*3000*4200 |
| Main machine weight | kg | 7000 |
